CAN-HUB
Overview
The Aces CAN Hub and BT-Module are designed to extend and simplify connectivity within the Aces EFI ecosystem. Both modules interface with the standard 4-pin CAN bus port available on all Aces ECUs and allow simultaneous use of multiple peripherals, including handheld tuners, laptops, and wireless devices.
Technical Specifications
Function:Ā
Expands one Aces CAN port into multiple CAN tap points.
Input/Output:Ā
1x Male CAN input, 2ā4x Female CAN outputs (varies by revision).
Supported Protocol:
CAN 2.0B, standard Aces communication.
Voltage Range:
12V (powered via CAN bus).
Termination:
Internally terminated CAN Bus
Physical Dimensions:
~1200mm x 400mm panel layout footprint.
Enclosure:
Sealed ABS.
Use Case Examples
- Race car tuning setups where multiple CAN devices must be online simultaneously (e.g., handheld tuner + laptop + QuickDraw).
- Mobile diagnostics via BT-Module in remote tuning support scenarios.
- Display system integration with future Aces CAN dash or data broadcast tools.
